3Q93 Pages 1 & 2


August 1993 7th Edition
Written by Bruce Clutcher and Faith Thompson
Edited by Bruce Clutcher Published by Faith Thompson


Background of Issue:

INVISION Pharmacy's IV Rate field (C1165) is defined as 3 characters integer. Because of this design, and until a data file change can be instituted, model will not support a decimal rate (e.g. 2.5 ml/hr). However, some clients require this support, especially for a pediatric IV (e.g. TPN solutions).

Ultimate Solution:

INVISION Pharmacy Product Planning has researched the issue and proposes to change the rate field from three characters integer ('999') to four/two characters decimal ('9999.99'). This will not only address the issue of decimal rates but also a related issue of supporting rates greater than 999 ml/hr (common in some adult oncology IV orders). This data file change and the corresponding programming adaptations to support the new field constitute a project reserved for major release boundaries. The next release has not been defined in any immediate development projects.

Interim Solution:

At least one client has successfully used an OAS adaptation to support decimal rates. The pediatric TPN example below coincided with a hospital policy to replace the IV bottle every 24 hours with a new bottle, even if the old bottle contained fluid to infuse. Whether this interim solution will meet your institution's needs should be evaluated in light of your current situation. Below is a brief description of the solution. Note there are several scenarios depending if you are processing a TPN/ALT TPN/ALT LVP (which cannot be processed as intermittent Ivs) or non TPN/ ALT TPN/ALT LVP:

1. TPN/ALT TPN/ALT LVP type Ivs:

2. Non TPN/ALT TPN/ALT LVP Continuous type IVs:

3. Non TPN/ALT TPN/ALT LVP Intermittent type IVs:


(by Faith Thompson)

When entering an order for an IV method type of TPN, Alternating TPN or Alternating LVP, the system uses more than one AUDA to hold all of the data for the order.

Currently, the programs which unload data from the Active Database into the Bottle Auda(s) DO NOT unload all Case and Visit data for the patient, but rather a subset of the data (see the attached list of data fields). Since the Bottle AUDA contents are used for printing IV labels, only the data subset which is unloaded into the Bottle AUDA is available for printing.

For example, Patient Birthdate (C0813), is NOT in the Bottle AUDA data list. Therefore, if the client wants to see the birthdate printed on TPN, ALT TPN, or ALT LVP labels, they would have to utilize one of the Bottle AUDA data fields to store birthdate. This would be accomplished by changing the admission/registration flow to DVA the birthdate (C0813) into a Bottle AUDA user-date field (C0744, C0745 or C0746).

Development is planning to change the programming logic so that all Case and Visit data components are available in the Bottle AUDA. This change is anticipated for 4Q93.


(by Bruce Clutcher)

All INVISION Rx Install Personnel need to be aware of a situation where you may lose all your assigned carts from the Room Segment during your pre-live building phase. As you know, when establishing Med/IV carts on INVISION, you must first create your carts by going into 'ADD A CART' in the 'MAINTAIN CART' functions. Doing this creates Cart Segments. The next step is to use the 'SPECIFY CART ID FOR ROOM' function to assign the appropriate cart ID to each hospital room. Doing this populates the five cart related fields in the Room Segment, C0606, C0607, C0935, C0611 & C0612.

A typical Room/Bed and Patient conversion (i.e. from an existing automated hospital system - e.g. Unity to INVISION conversion) involves the following three steps:

In addition, your hospital may or may not have manually built their room beds on the clinical side prior to the Test Conversion.

If your hospital manually built the clinical Room Segment (before a Test Conversion) and you assigned your carts to the rooms prior to the Test Conversion, you will lose all cart information in the Room Segment if the File Conversions Group pulls the Room information from financials. Since the Financial system contains only financial room information and no cart information, the Test Conversion, by its nature, will overlay and lose your Room Segment cart information.

The recommendation therefore, is to either:
